The Unity Architecture I Reuse Across Casual Game Projects

🧩 Why bother with a standard architecture?

After shipping several casual/hyper-casual projects, I learned that without a clear framework from day one, code turns messy fast — especially when handing off, extending features, or coming back to fix things months later. This post walks through the code structure I reuse in most of my projects, along with real code samples.

📌 Overall system diagram

Overall Unity architecture diagram Entry scene spawns a persistent manager group (UIManager, ResourcesManager, SoArchitecture, SaveDataHandler, AudioManager). Below it, a scene Controller bridges gameplay objects and the View/Popup UI layer. Entry scene Persistent managers Spawned once, DontDestroyOnLoad UIManager Views & popups Resources manager Shared ScriptableObjects SoArchitecture Event hub (observer) Save data handler PlayerPrefs + JSON Audio manager Music & SFX Scene controller Singleton, not persistent Gameplay objects CarController, ... View / popup Only renders data

🏗️ Core principle: the Controller is the single point of communication

The most important rule in this architecture: objects inside a scene are never allowed to call GUI/View directly. Every interaction between gameplay and UI must go through that scene’s Controller.

1
2
3
4
5
6
7
Gameplay Object (e.g. CarController)
        │
        ▼
   Scene Controller (e.g. GameController)
        │
        ▼
      UIView (e.g. GameView) ── only receives data to display

For example, inside GameController, every frame it pulls data from CarController and pushes it to GameView to render — CarController never calls GameView directly:

1
2
3
4
5
6
7
8
9
private void UpdateGameplayStats()
{
    if (carController == null || gameView == null) return;

    float distance = carController.DistanceTraveled;

    gameView.UpdateSpeed(carController.CurrentSpeed);
    gameView.UpdateDistance(distance);
}

The benefit: gameplay logic stays fully decoupled from UI. Swapping the UI or adding a new view never requires touching gameplay logic.

🔁 The Singleton system — 3 flavors for 3 different lifetimes

I keep a single BaseSingleton.cs file defining 3 kinds of singleton, picked depending on the lifetime I need:

Type Behavior Used for
Singleton<T> Plain class (where T : new()), creates its own instance lazily Pure logic classes that don’t need MonoBehaviour
ManualSingletonMono<T> Only returns an instance that already exists in the scene — never creates one, logs an error if missing Manager classes that must be set up in a scene/prefab (UIManager, ResourcesManager, GameController…)
AutoSingletonMono<T> Automatically spawns a new GameObject if no instance exists yet Utility helpers that don’t need manual setup

The neat part: ManualSingletonMono<T> never calls DontDestroyOnLoad itself — whether it persists across scenes is entirely decided by where it’s instantiated (see the Entry Scene section below), not by the Singleton base class.

🚪 Entry Scene — where every persistent system gets bootstrapped

The very first scene (Entry) has one job: show a loading bar, then DontDestroyOnLoad a single manager prefab holding every system-level Manager, before switching to the Main scene.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
private void Awake()
{
    Application.targetFrameRate = 60;
    loadDuration = Random.Range(2, 3);
    DontDestroyOnLoad(manager);
}

private void Start()
{
    slider.value = 0f;
    slider.DOValue(100f, loadDuration)
        .SetEase(Ease.OutCubic)
        .OnComplete(() => { SceneManager.LoadScene(GameConstants.SceneMain); })
        .OnUpdate(() => { textPercenst.text = "Loading..." + Mathf.RoundToInt(slider.value) + "%"; });
}

Thanks to this, the managers below live for the entire lifetime of the app, independent of scene reloads:

  • UIManager — manages every Canvas in the game (View + Popup + Alert), spawned from the Entry scene, DontDestroyOnLoad.
  • ResourcesManager — stores and manages shared ScriptableObjects, DontDestroyOnLoad.
  • SoArchitectureManager — the event hub (Scriptable Object Architecture), DontDestroyOnLoad.
  • SaveDataHandler — reads/writes local save data (PlayerPrefs), DontDestroyOnLoad.
  • AudioManager — manages background music and sound effects, DontDestroyOnLoad.
  • GameConstants — shared constants: scene names, popup resource paths…

🎮 Controller — the brain of each scene

Unlike the Managers above, a Controller is a singleton but is NOT DontDestroyOnLoad — it only lives within its own scene (MainController for the Main scene, GameController for the Game scene).

1
2
3
4
5
6
7
8
9
10
public class GameController : ManualSingletonMono<GameController>
{
    private void Start()
    {
        RegisterEvents();
        UIManager.Instance.ViewManager.ShowView(UIViewName.GameView);
        gameView = UIManager.Instance.ViewManager.GetViewByName<GameView>(UIViewName.GameView);
    }
    ...
}

The Controller’s job:

  • Acts as the only bridge between the current scene and the DontDestroyOnLoad Managers above (UIManager, SoArchitectureManager…).
  • Drives input, gameplay state (pause/resume/end game), and pushes data to the matching View.
  • Registers/unregisters events right inside RegisterEvents() / UnregisterEvents() — preventing listener leaks when switching scenes.

🖼️ The UI system: UIManager → ViewManager & PopupManager

UIManager

UIManager is a DontDestroyOnLoad singleton holding references to 3 sub-managers: ViewManager, PopupManager, AlertManager. It also handles the loading screen and scene-transition effects (using DOTween scale in/out).

View — a full-screen canvas per scene

UIViewManager manages Views (full-screen canvases per scene, e.g. MainView, GameView). Built-in features include:

  • A history stack of shown views (LastShownView) to support a Back button.
  • HideOthersView() auto-hides other views when showing a new one, avoiding overlapping UI.
  • OnShownCallBack / OnHideCallBack callbacks to keep the topbar and back button in sync.

UIPopupManager manages Popups (SettingPopup, ShopPopup, TutorialPopup, UpgradePopup…) using 2 dictionaries:

  • _dictPopup: caches created popup instances → reused instead of being recreated over and over.
  • _dictPopupControllers: dedicated controllers driving the show/hide/animation logic for each popup.
1
2
3
4
5
6
7
8
9
public UIPopup GetPopupFromCacheOrCreate(UIPopupName name)
{
    UIPopup popup = GetPopup(name);
    if (popup) return popup; // already exists -> reuse

    popup = CreateDefaultPopup(name); // doesn't exist -> create & cache it
    ...
    return popup;
}

Each Popup inherits from UIPopup and overrides OnShowing() / OnHiding() to handle its own logic (e.g. SettingPopup pauses/resumes the game automatically when opened/closed).

📡 Data & Events: SoArchitectureManager, ResourcesManager, SaveDataHandler

SoArchitectureManager — an Observer pattern built on ScriptableObjects

Instead of systems calling each other directly (which quickly creates tangled dependencies), everything communicates through a GameEvent ScriptableObject:

1
2
3
4
5
6
public class SoArchitectureManager : ManualSingletonMono<SoArchitectureManager>
{
    public IntGameEvent OnMoneyChangedEvent;
    public GameEvent PauseGame;
    public GameEvent ResumeGame;
}

Anything can AddListener/RemoveListener or Raise() without knowing who’s listening — reducing coupling between systems (Controllers, Views, and Popups can all listen to OnMoneyChangedEvent without holding a direct reference to each other).

ResourcesManager

A single place to store and load ScriptableObjects shared across the whole game (item data, config…), instead of scattering Resources.Load calls everywhere.

SaveDataHandler

Persists local data via PlayerPrefs + JsonUtility, auto-saving on app pause/quit/disable, and exposing RequestSave() to batch multiple changes and save once in Update() instead of saving on every single change (which would cause hitches):

1
2
3
4
5
6
7
8
private void Update()
{
    if (_requestSave)
    {
        _requestSave = false;
        OnSaveData();
    }
}

🔊 AudioManager

Manages background music and sound effects (SFX), keeps separate volume settings for music/SFX, and is called directly by Popups/Views whenever needed (e.g. SettingPopup syncs the volume sliders, GameView plays an SFX on button press).

🧰 Shared Utilities

  • SimplePool — a lightweight object pool, avoiding repeated Instantiate/Destroy calls (extremely handy for bullets, coins, or any object that spawns constantly in a casual game).
  • SafeArea — automatically fits UI to the screen’s safe area on notched devices, attached directly to the RectTransform of whichever panel needs it.

✅ Summary: a full play session flow

  1. Entry scene → EntryController shows the loading bar, DontDestroyOnLoads the manager prefab, then loads the Main scene.
  2. Main scene → MainController shows MainView, waiting for the player to hit Play.
  3. Pressing Play → UIManager.Instance.ShowTransition() → loads the Game scene.
  4. Game scene → GameController shows GameView, registers events from SoArchitectureManager, and every frame pushes gameplay data (CarController) to GameView to render.
  5. Game over → GameController.ShowEndGame() → UIManager.Instance.PopupManager.ShowPopup(...).

Throughout this whole flow, every piece only talks to the others through Controllers + Managers + Events — no gameplay object ever reaches into the UI, and no UI ever reaches into gameplay.

🎯 When is this architecture worth it?

Best suited for:

  • Casual/hyper-casual projects that need to move fast with several simple scenes (Entry → Main → Game).
  • Small teams that need a shared standard new members can onboard onto quickly.

It can feel like overkill for a tiny 1-2 screen prototype — in that case, dropping the Controller/Event layer and calling things directly is often faster.

This post is based on the code framework I keep reusing across projects at Denk Studio.
